| 標準手機通用充電器 |
公司目前已進入自主開發階段，開發出一系列以電子、塑膠為主的新特網絡通訊設備，請國內（特別是廣東、深圳本地）相關配件廠家提供相關配件，儘快與我們取得聯繫（Email:join2@126.com),成為我們的配件供應商 Company is now in its development phase, to develop a series of electronic, plastic-based new special network communications equipment, please domestic (especially Guangdong, Shenzhen local) related accessories manufacturers provide related accessories, as soon as we made contact with (Email:join2@126.com), a supplier of our accessories
|
|
參數說明 型號 :LTD-0902 USB 系列 開關型插牆式充電器
殼體尺寸(長*寬*高):60*26.5*42.5mm
成品淨重:38.5g
工作溫度:0~40℃
存儲溫度:-40~70℃
存儲濕度:10-90%
EMC:FCC part15(CLASS B)
安全許可:CCC SAFE
額定輸入電壓:90~264VAC
平均效率:≥50%
1、輸入:
1-1.輸入電壓 :90~264VAC
1-2.輸入頻率 :47~63 Hz
1-3.輸入電流 :≤150mA
2、輸出:
2-1.輸出電壓 :+5.4VDC
2-2.電壓精度 :+5.4 V±0.4VDC
2-3.輸出電流 :500mA DC
2-4.電流精度 :500mA±50ma DC
3、保護裝置:
3-1.過流保護 :≤950mA
3-2.過壓保護 :6.2V MAX
4、環境
4-1.工作溫度 :0~40 ℃
4-2.工作濕度 :10~90%
4-3.存儲溫度 :-40~70 ℃
4-4.存儲濕度 :5~95%
5、 高壓測試及洩漏電流:
5-1.輸入到輸出部分 :3KV 10mA 1sec
5-2.洩漏電流 :≤0.25mA
5-3.絕緣阻抗 :≥50MΩ,500VDC
6、安全及電磁兼容
6-1.安全標準 :CCC SAFE
6-2.電磁兼容標準 :FCC Part 15(CLASS B)
|
|
|
|
|
|
創新產品-塑膠工模水嘴，以特殊工程材料完全代替銅管注塑工模冷卻水嘴，其韌度和耐用度則遠遠高于傳統銅管注塑工模冷卻水嘴，而價格只是銅管注塑工模冷卻水嘴的一半，而且不再需要使用防水膠布，本產品由我公司工程技術部獨立開發，現已申報中國國家專利產品的過程中，並率先投放市場，歡迎相關業者捷足先登前來洽談訂購
Innovative products - plastic mould Shuizui to special engineering materials fully replace brass cast mould cooling Shuizui its consistency and durability degrees is far higher than traditional brass cast mould cooling Shuizui, and the price is only brass cast mould cooling Shuizui half, but no longer need to use waterproof tape, the products from our company engineering department independent development, Chinese patent products now declare the process, and to put on the market, welcomed the relevant operators to discuss their marks ordered |
|
|
|
|
|
|
|
|
